FLM Series

QUICK OVERVIEW

Product Code:563
Brand:fluorometer
FLM Series

Share this product on social networks

The FLM Series is a dual-channel fluorometer , it provides high-sensitive fluorescent detection when quantifying nucleic acids and proteins, simple and cost to operate Applications:

1.The sample is scarce and difficult in processing

  1. 2. The low quantity of DNA, RNA, or protein after extraction
  2. 3. The sample will be used in the expensive experiments: qPCR, PCR cloning, transfection, the next generation sequencing and et

Fluorometer technical background

– Our nano series Micro-Spectro photometer measure the concentration and purity of the sample, because it is able to measure the absorbance of the whole ingredient (such as DNA, RNA, oligos and so on) of the sample at 260 nm, that may make the read inaccuracy. While the fluorometer measure the fluorescence intensity of the fluorescent reagent which combine with the target molecule to read the concentration of sample. Generally, the read is lower than Nano series products but much accuracy than it .
– The sensitivity of Nano series products are above 5ng/ul, and while the fluor ometer is 0.5pg/ul in measuring DNA concentration. It is important and necessary for the most applications to read the lower and accuracy concentration of the sample.

– Using the FLM SERIES fluor meter with the quantification kit can measure the sample concentration rapidly, sensitively and accurately  .

Quantification kit
High sensitivity of dsDNA Quantitative Kit: 0.2–100ng
– High sensitivity of ssDNA Quantification Kit: 1–200ng
– Broad range of dsDNA Quantification Kit: 100–1600ng
– Protein Quantification Kit is researching

TECHNICAL SPECIFICATION


Model Light Excitation Filters Emission Filters
FLM-365 UV 365±20nm 420-480nm (60nm)
Blue 460±20nm 525-570nm (45nm)
FLM-625 Blue 460±20nm 525-570nm (45nm)
Red 625±10nm 670-725nm (55nm)
FLM-525 Blue 460±20nm 525-570nm (45nm)
Green 525±20nm 575-640nm (65nm)

Application of different fluorescence channel:

Channel

Excitation Filters

Normal kits

Applications

UV channel

365±20nm

Hoechst 33258, 4-MU,

Nuclear acid quantification, Plant GUS reporter gene detection, Poptosis detection

 EnZCheK Caspase

Blue channel

460±20nm

Pico Green®, oligreen,RiboGreen®,

dsDNA, ssDNA, RNA quantification, GFP gene detection,

GFP, Protein, Fluorescein, Quant-iT™

 Fluorescein detection, Protein detection

Green channel

525±20nm

Rhodamine, Cy3,

Rhoda mine detection, Cy-3 fluorescence labeling detection,

RFP Vybrant Cytotoxicity

 RFP gene detection, Cell activity poison detection

Red channel

625±10nm

Cy5, Quant-iT RNA

Cy-5 fluorescence labeling detection, RNA quantification
